Kit Model
IP-KIT8662
Camera Model
IPC-T260HAP-LUF/SL 6pcs
NVR Model
NVR-208MH-C/8P(D)(2T)
IP Video Input
8-ch
HDMI Output
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz
VGA Output
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding Format
H.265+/H.265/H.264+/H.264
Recording Resolution
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Decoding Capability
1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
Audio Compression
G.711ulaw/G.711alaw/G.722/G.726
Network Interface
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface
PoE Interface
8-ch, RJ-45 10/100 Mbps self-adaptive Ethernet interface
PoE Power
≤ 50 W
PoE Standard
IEEE 802.3 af/at
